Paint Code Matches*
Last Update:  10/16/04

*  Many are searching for modern paint codes for their Triples.  Although original codes are referenced elsewhere on this site, they usually cannot be matched from the codes given.  Color-Rite (www.color-Rite.com) has the rights to the official Kawasaki color info, however, they don't go back as far as needed for Triples.  The best way I have found to match paint is thru the use of a spectrometer.  A quality automotive paint house should have one available.  It will be necessary to have a sample of the desired color to match.  Be aware that base coat color can make a difference in the shade of the final coat. The codes listed below are submitted from various sources and should be used at your own risk.  Please offer any additions to triple.dale@gmail.com .

A recommended source for paint is RS Bike Paint

Early H1 and S engine cover paint matches = Harley Davidson silver case paint  or Mopar "Argent Silver".

H1A/H2-Blue > PPG# DBU
Mix:
649-40                 200.0
660-44                   20.0
661-45                     5.0
658-91                 230.0
DX 820-101           50.0
PRL 98-103           12.0
PRL 87-103.5          2.5
DBX 695-.515      515.0
or
HOK-
Oriental Candy Blue w/white base
H1-Midnight

 White >

Chrysler "W1"
Stone White

Stripe/Letters:
Mactac 9839-19 or
Dark Blue +/- RAL 5011
H2B-Brown > PPG# DBU2590
Mix:
DMD669           13.2
DMD622           10.9
DMD635           22.8
DMD623         120.2
DMD647         136.6
DBX695          212.8

  H1-Peacock
     Grey >

PPG# DBU
Mix:
M117- 89.2
M123- 139.9
M121- 4.9
M135- 14.4
M120- 5.0
M150- 246.2

H2B-Green >



Dupont YM554 H1-'70 Candy
      Red >
PPG Deltron 2000 paint
DMD1692  Red                    6.1
DMD617    Orange            224.0
DMD1609   Quindo violet   177.4
DMD1690   Crs. Alum         33.8
DMD1683   Black                 .06
DBX1689    Clear               120.3


    H2C-Purple >    Use PPG# DBU paint:
DMD624         200 parts
DMD649           50 parts
DMD664           10 parts
DBX695         300 parts
PRL90                5 parts
F21                  0.6 parts
F36                  0.3 parts
Total parts = 565.9
  H1B-Orange >    PPG# DBU2186
Mix:
DMD631          8.5
DMD651          1.5
DMD618        25.8
DMD617      134.3
DBX695       111.5
or
PPG# DBC2186
Mix:
DMD617      207.0
DMD618        39.7
DMD1686      27.8
DMD1687      12.1
DBX1689     271.7
S3A/H2C-
Candy
 Super
      Red >
Dupont 1984  USA Honda -
Dark Red Metallic B/C:
858J Deep Maroon      88.7
866J Red Violet         115.5
867J Red                    137.9
806J HS Black           154.4
818J Bright Adjust    168.5
802J LS White            169.4
1006S Copper Pearl  172.2
1002S Red Pearl        174.6
150K B/C Balancer

H1D-Green >

PPG# DBC47414
Mix:
DMD1683     221.1
DMD1678     210.4
DMD1693         4.4
PRL93             20.9
DMD646          12.3
DBX1689        43.6

H1E-Green > Use PPG# 4301 H1E-Candy
      Red >
'09-'10 Honda car
Dark Cherry Pearl
Honda code R529P
